Ruijie Switch RG-S5760C-48SFP4XS-X 48 SFP Ports 10G Uplinks VSU Stacking For Enterprise Core Networks

Large Image : Ruijie Switch RG-S5760C-48SFP4XS-X 48 SFP Ports 10G Uplinks VSU Stacking For Enterprise Core Networks

Product Details:

Brand Name:	Ruijie
Model Number:	RG-S5760C-48SFP4XS-X

Contact Now

Ruijie Switch RG-S5760C-48SFP4XS-X 48 SFP Ports 10G Uplinks VSU Stacking For Enterprise Core Networks

Description

Management Interface:	Console, Telnet, SSH, Web	Power Consumption:	≤ 60W
Forwarding Rate:	131Mpps	Power Supply:	AC 100-240V, 50/60Hz
Switching Capacity:	176Gbps	Dimensions:	440mm X 44mm X 220mm
Operating Temperature:	0°C To 45°C	Qos Support:	Yes
Port Speed:	10/100/1000Mbps	Port Number:	48
Vlan Support:	Yes	Weight:	3.2kg
Highlight:	Enterprise Core Networks Switch , SFP Ports 10G Uplinks Switch , 10G Uplinks VSU Stacking Switch

Ruijie Switch RG-S5760C-48SFP4XS-X 48 SFP Ports 10G Uplinks & VSU Stacking For Enterprise Core Networks

The Ruijie RG-S5760C-48SFP4XS-X is a next-generation Layer 3 managed switch designed for enterprise core and data center networks, offering high-speed connectivity, advanced security, and flexible scalability. With 48x 1G SFP ports and 4x 10G SFP+ uplinks, this switch ensures high-bandwidth, low-latency performance for demanding business applications.

Key Features & Benefits

High-Density Fiber Connectivity - 48x Gigabit SFP ports support fiber optics for long-distance, high-speed data transmission.
10G Uplinks for Scalability - 4x 10G SFP+ ports provide high-speed aggregation, ideal for backbone connections.
VSU Virtual Stacking Technology - Combine multiple switches into a single logical device for simplified management & redundancy.
Advanced Security & QoS - Supports ACL, DHCP Snooping, IP-MAC Binding, and traffic prioritization for optimized performance.
Reliable & Energy-Efficient - Redundant power supply (optional), low power consumption, and fan redundancy ensure 24/7 operation.

Technical Specifications

Specification	Details
Ports	48x 1G SFP, 4x 10G SFP+
Switching Capacity	256 Gbps
Forwarding Rate	96 Mpps
Stacking	VSU (Virtual Switching Unit)
Layer 3 Features	OSPF, BGP, VRF, IPv6
Security	ACL, 802.1X, Anti-ARP Spoofing
Power Supply	Dual hot-swappable (optional)

Ideal Use Cases

Enterprise Core Networks - High-speed backbone for large offices & campuses.

Data Center Aggregation - Reliable 10G uplinks for server connectivity.

ISP & Metro Networks - Fiber-based deployments with advanced routing.

This Ruijie switch delivers enterprise-grade performance, scalability, and security, making it a cost-effective solution for modern high-speed networks. Upgrade your infrastructure with Ruijie's reliable networking technology today!
