Wireless Standards: | IEEE 802.11a/b/g/n/ac | Weight: | 0.5kg |
---|---|---|---|
Maximum Data Rate: | 1.167Gbps | Management: | Web, CLI, SNMP |
Security: | WPA/WPA2-PSK, WPA/WPA2-Enterprise, 802.1x | Mimo Technology: | 2x2 MIMO |
Dimensions: | 200mm X 200mm X 40mm | Operating Temperature: | 0°C To 40°C |
Power Consumption: | 12W | Frequency Band: | 2.4GHz/5GHz |
Mounting Options: | Ceiling Or Wall Mount | Antenna: | Internal 2.4GHz: 2x2 MIMO, 5GHz: 2x2 MIMO |
Power Supply: | PoE Or DC 12V | Model: | RG-AP1100P |
Highlight: | Ruijie RG-AP1100P Wi-Fi 6 AP,dual-band wireless access point,1.167Gbps Ruijie AP |
Attribute | Value |
---|---|
Wireless Standards | IEEE 802.11a/b/g/n/ac |
Weight | 0.5kg |
Maximum Data Rate | 1.167Gbps |
Management | Web, CLI, SNMP |
Security | WPA/WPA2-PSK, WPA/WPA2-Enterprise, 802.1x |
MIMO Technology | 2x2 MIMO |
Dimensions | 200mm x 200mm x 40mm |
Operating Temperature | 0°C to 40°C |
Power Consumption | 12W |
Frequency Band | 2.4GHz/5GHz |
Mounting Options | Ceiling or wall mount |
Antenna | Internal 2.4GHz: 2x2 MIMO, 5GHz: 2x2 MIMO |
Power Supply | PoE or DC 12V |
Model | RG-AP1100P |
The Ruijie RG-AP680-CD-A(V3) Wireless AP delivers next-generation Wi-Fi 6 (802.11ax) performance, ideal for high-density environments like offices, schools, and hospitals. With dual-band concurrent operation (2.4GHz & 5GHz) and a combined speed of 5.377Gbps, it ensures seamless connectivity for bandwidth-intensive applications, including 4K video streaming, cloud computing, and IoT deployments.
Parameter | Specification |
---|---|
Wi-Fi Standard | 802.11ax (Wi-Fi 6) |
Frequency Bands | Dual-band (2.4GHz & 5GHz) |
Max Speed | 5.377Gbps (574Mbps + 4.8Gbps) |
MIMO Configuration | 4×4:4 MU-MIMO |
Antennas | Internal high-gain omni-directional |
PoE Support | 802.3bt (PoE++) |
Max Clients | 100+ per AP |
Security | WPA3, AES encryption, ACL, RADIUS |
Management | Local forwarding, cloud/on-prem control |
Ruijie's RG-AP680-CD-A(V3) combines cutting-edge Wi-Fi 6 performance, enterprise security, and easy deployment—making it a top choice for businesses needing scalable, future-proof wireless networking.
