Ruijie RG-IOA-2503-X9 Industrial IoT Gateway With Edge Computing

Large Image : Ruijie RG-IOA-2503-X9 Industrial IoT Gateway With Edge Computing

Product Details:

Brand Name:	Ruijie
Model Number:	RG-IOA-2503-X9

Contact Now

Ruijie RG-IOA-2503-X9 Industrial IoT Gateway With Edge Computing

Description

Antenna:	Internal/External	Mounting Options:	Ceiling/Wall Mount
Weight:	0.5kg	Frequency Band:	2.4GHz/5GHz
Security Features:	WPA/WPA2, 802.1X, MAC Filtering	Number Of Users:	Up To 200 Concurrent Users
Maximum Data Rate:	1.3Gbps	Power Supply:	PoE/DC
Operating Temperature:	0°C To 40°C	Management Features:	Web-based GUI, CLI, SNMP
Wireless Standards:	IEEE 802.11a/b/g/n/ac	Dimensions:	200mm X 200mm X 40mm
Highlight:	Ruijie industrial IoT gateway with edge computing , Ruijie wireless AP with IoT support , industrial IoT gateway

Ruijie RG-IOA-2503-X9 Industrial IoT Gateway With Multi-Protocol Support & Edge Computing

The Ruijie RG-IOA-2503-X9 is a rugged Industrial IoT (IIoT) Gateway designed for reliable data acquisition, edge computing, and secure cloud connectivity in harsh environments. Supporting multi-protocol communication, industrial-grade durability, and AI-ready edge processing, it enables seamless integration of legacy and smart devices in smart factories, energy grids, and transportation systems.

Key Features & Benefits

Industrial-Grade Reliability

Operates in -40°C to 75°C with EMI/anti-vibration protection (IEC 61000-6-2/4 certified)
Fanless metal housing for 24/7 stability in dust, humidity, and high-noise areas

Multi-Protocol & Multi-Interface Support

Wide compatibility: Modbus, OPC UA, MQTT, IEC 104, and more
Diverse ports: RS-232/485, Gigabit Ethernet, DI/DO, and optional 4G/5G/Wi-Fi/LoRa

Edge Computing & AI Capabilities

Local data processing (filtering, aggregation) to reduce latency & bandwidth costs
Optional AI acceleration for predictive maintenance and anomaly detection

Enterprise-Grade Security

End-to-end encryption (TLS/SSL), VPN (IPSec/OpenVPN), and firewall
Role-based access control (RBAC) to prevent unauthorized access

Cloud & Remote Management

Pre-integrated with Ruijie IoT Platform, AWS IoT, and Alibaba Cloud
Supports Docker containers for custom app deployment

Technical Specifications

Category	Details
CPU	Quad-core ARM Cortex-A55 @ 1.5GHz
Memory/Storage	2GB DDR4 / 8GB eMMC (expandable)
Interfaces	2x Gigabit Ethernet, 2x RS-485, 4x DI/DO
Wireless	Optional 4G/5G, Wi-Fi 6, LoRa
Protocols	Modbus RTU/TCP, MQTT, OPC UA, IEC 60870-5-104
Power Input	12~48V DC (wide voltage)
Certifications	CE, FCC, IEC 61000-6-2/4

Why Choose Ruijie RG-IOA-2503-X9?
Ideal for Industry 4.0 applications, this gateway bridges OT and IT systems with high throughput (up to 10K packets/sec), low-latency edge analytics, and military-grade security. Its modular design ensures scalability for future upgrades.
