Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support

I'm Online Chat Now

Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support

Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support
Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support

Large Image :  Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support

Product Details:
Brand Name: Ruijie
Model Number: RG-S6250-48XS8CQ

Ruijie Switch 48x25G Ports With VSU Stacking And RoCEv2 Support

Description
Product Series: Ruijie Switch Port Speed: 10/100/1000Mbps
Port Type: Ethernet Number Of Ports: 24/48
Forwarding Rate: Up To 71.4Mpps Power Supply: AC/DC
Switching Capacity: Up To 128Gbps Model: Ruijie Switch
Power Consumption: Max. 30W Management Interface: Web, CLI, SNMP
Product Type: Switch Qos Support: Yes
Highlight:

RoCEv2 Support Ruijie Switch

,

25G Ports Ruijie Switch

,

VSU Stacking Ruijie Switch

Ruijie Switch With 48x25G Ports VSU Stacking RoCEv2 & Secure Cloud Networking
Product Attributes
Attribute Value
Product Series Ruijie Switch
Port Speed 10/100/1000Mbps
Port Type Ethernet
Number Of Ports 24/48
Forwarding Rate Up to 71.4Mpps
Power Supply AC/DC
Switching Capacity Up to 128Gbps
Model Ruijie Switch
Power Consumption Max. 30W
Management Interface Web, CLI, SNMP
Product Type Switch
Qos Support Yes
Product Description

The Ruijie RG-S6250-48XS8CQ is a high-performance data center and enterprise core switch designed for ultra-low latency, high-density 25G/10G server access, and scalable cloud networking.

Key Features & Benefits
  • High-Speed Adaptive Ports - Supports 10G/25G at the access layer and 40G/100G uplinks, with QSFP28 breakout for flexible deployment.
  • VSU Virtual Stacking - Combine up to 8 switches into a single logical device, simplifying management and enhancing redundancy.
  • RoCEv2 & Data Center Optimized - Enables RDMA over Converged Ethernet for low-latency storage (NVMe-oF) and AI/ML clusters.
  • Secure Cloud Networking - Features MACsec encryption, DDoS protection, and automated SDN integration (OpenFlow 1.3, RESTful APIs).
  • Energy Efficient - IEEE 802.3az (EEE) compliance and dynamic power adjustment reduce operational costs.
Technical Specifications
Model RG-S6250-48XS8CQ
Ports 48x 10G/25G SFP28 + 8x 40G/100G QSFP28
Switching Capacity 3.84 Tbps
Forwarding Rate 1,440 Mpps
Latency <1μs (Cut-Through mode)
Stacking VSU (Virtual Switching Unit), up to 8 units
Security MACsec, ACLs, DAI, Private VLAN
Cloud Integration OpenStack, Azure Stack, Telemetry for analytics
Power Consumption <300W (typical)
Ideal Use Cases
  • Cloud Data Centers - High-speed server connectivity with RoCEv2 for NVMe/TCP and GPU clusters.
  • Enterprise Core Networks - Scalable 25G spine-leaf architecture with VSU stacking.
  • Financial/HPC Environments - Sub-microsecond latency for algorithmic trading and high-performance computing.

Optimized for future-ready networks, the Ruijie S6250-48XS8CQ combines high density, low latency, and secure automation in a single platform. Upgrade to 25G/100G today!
