Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+

I'm Online Chat Now

Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+

Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+
Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+ Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+ Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+ Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+ Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+ Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+

Large Image :  Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+

Product Details:
Brand Name: Ruijie
Model Number: RG-S6501-48VS8CQ

Ruijie RG-S6501-48VS8CQ 48-Port PoE+ Switch With 8x 10G SFP+

Description
Power Supply: AC 100-240V, 50/60Hz Dimensions: 440mm X 220mm X 44mm
Series: Ruijie Switch Port: 10/100/1000Base-T
Forwarding Rate: 44.8Mpps Weight: 2.5kg
Poe Support: Yes Vlan Support: Yes
Port Quantity: 24 Management Interface: Console, Telnet, SSH, Web
Mac Address Table Size: 16K Model: Ruijie Switch
Highlight:

S6501-48VS8CQ

,

10G SFP+ 48-Port PoE+ Switch

,

48-Port PoE+ Switch

Ruijie Switch RG-S6501-48VS8CQ 48-Port PoE+ & 8x 10G SFP+ High-Performance Layer 3 Switch
Product Overview

The Ruijie RG-S6501-48VS8CQ is a high-performance Layer 3 managed switch designed for enterprise networks, offering 48x Gigabit PoE+ ports and 8x 10G SFP+ uplinks for scalable, high-bandwidth connectivity. Ideal for PoE-powered devices (IP cameras, wireless APs, VoIP phones) and data-intensive applications, this switch delivers robust security, advanced QoS, and flexible deployment options.

Key Features
  • High-Density PoE+ Support: All 48x RJ45 ports provide IEEE 802.3af/at PoE+ (up to 30W per port), with a total PoE budget of 740W
  • 10G Uplinks: 8x SFP+ slots enable 10G fiber or DAC connections for high-speed aggregation
  • Layer 3 Routing: Supports static routing, OSPF, RIP, and VLAN routing for efficient inter-subnet communication
  • Enterprise Security: Features ACLs, 802.1X authentication, port security, and anti-ARP spoofing
  • Virtualization & Redundancy: VSF stacking for up to 8 switches with MSTP/RSTP support
Technical Specifications
Category Details
Ports 48x 10/100/1000BASE-T (PoE+), 8x 10G SFP+
PoE Budget 740W total (max 30W/port)
Switching Capacity 256 Gbps
Forwarding Rate 96 Mpps
Routing Protocols Static, RIP, OSPF
Security ACLs, 802.1X, MAC binding, DHCP snooping
Management Web UI, CLI, SNMP, RGOS (Ruijie OS)
Power Supply Dual hot-swappable PSUs (optional)
Product Attributes
Attribute Value
Power Supply AC 100-240V, 50/60Hz
Dimensions 440mm x 220mm x 44mm
Series Ruijie Switch
Port 10/100/1000Base-T
Forwarding Rate 44.8Mpps
Weight 2.5kg
Poe Support Yes
Vlan Support Yes
Port Quantity 24
Management Interface Console, Telnet, SSH, Web
Mac Address Table Size 16K
Model Ruijie Switch
Ideal Applications
  • Enterprise/Campus Networks: Aggregation for Wi-Fi 6 APs, IP surveillance, and VoIP systems
  • Data Center Edge: High-speed 10G uplinks to servers or storage
  • Smart Buildings: Unified PoE+ power for IoT devices
