Ruijie Switch RG-S6580-48CQ8QC 48-Port 25G/10G With 8x100G SDN VXLAN

Large Image : Ruijie Switch RG-S6580-48CQ8QC 48-Port 25G/10G With 8x100G SDN VXLAN

Product Details:

Brand Name:	Ruijie
Model Number:	RG-S6580-48CQ8QC

Contact Now

Ruijie Switch RG-S6580-48CQ8QC 48-Port 25G/10G With 8x100G SDN VXLAN

Description

Switching Capacity:	176Gbps	Qos Support:	Yes
Port Type:	Gigabit Ethernet	Redundancy Features:	STP, RSTP, MSTP
Power Supply:	AC 100-240V	Vlan Support:	Yes
Poe Support:	Yes	Security Features:	802.1X, ACL, RADIUS, TACACS+
Number Of Ports:	48	Mac Address Table Size:	32K
Management Interface:	Web, CLI, SNMP	Model:	RG-S5750E
Forwarding Rate:	130.95Mpps	Link Aggregation:	Yes
Highlight:	SDN VXLAN Ruijie Switch , 48-Port 25G/10G Ruijie Switch , 8x100G Ruijie Switch

Ruijie Switch RG-S6580-48CQ8QC 48-Port 25G/10G + 8x100G SDN & VXLAN Support For Data Center

Product Attributes

Attribute	Value
Switching Capacity	176Gbps
Qos Support	Yes
Port Type	Gigabit Ethernet
Redundancy Features	STP, RSTP, MSTP
Power Supply	AC 100-240V
Vlan Support	Yes
Poe Support	Yes
Security Features	802.1X, ACL, RADIUS, TACACS+
Number Of Ports	48
Mac Address Table Size	32K
Management Interface	Web, CLI, SNMP
Model	RG-S5750E
Forwarding Rate	130.95Mpps
Link Aggregation	Yes

Product Description

The Ruijie RG-S6580-48CQ8QC is a next-generation data center switch designed for high-performance cloud, virtualization, and enterprise networks. Featuring 48x 25G/10G SFP28 ports and 8x 100G QSFP28 uplinks, it delivers ultra-low latency, high throughput, and flexible scalability for modern IT infrastructure. With SDN support, VXLAN overlay networking, and advanced automation, this switch is ideal for dynamic cloud environments, AI/ML workloads, and large-scale data centers.

Key Features & Benefits

High-Speed Connectivity - 48x 25G/10G ports + 8x 100G uplinks for seamless server-to-core networking.
SDN & Cloud-Ready - Supports OpenFlow, RESTful APIs, and VXLAN for software-defined data centers.
Enterprise-Grade Reliability - Redundant power supplies, hot-swappable fans, and 99.999% uptime.
AI-Optimized Traffic Management - Advanced QoS, telemetry, and congestion control for latency-sensitive apps.
Secure & Scalable - Built-in ACLs, anti-DDoS, and VSX (virtual switching extension) for resilient networks.

Technical Specifications

Category	Specifications
Ports	48x 25G/10G SFP28, 8x 100G QSFP28
Switching Capacity	3.2 Tbps
Forwarding Rate	2.4 Bpps
Latency	<1μs (cut-through)
Virtualization	VXLAN, VRF, VSU (Virtual Switching Unit)
SDN Support	OpenFlow 1.3, NETCONF, REST API
Security	ACL, DHCP Snooping, IP-MAC Binding
Power Supply	Dual 1+1 Redundant (1100W)
Cooling	Hot-swappable fans

Ideal Use Cases

Cloud & Hyperscale Data Centers - Supports multi-tenant VXLAN segmentation.
AI/ML & HPC Clusters - Ultra-low latency for distributed computing.
Enterprise Core/Aggregation - High-density 25G/10G server access with 100G spine-leaf uplinks.
