16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch

I'm Online Chat Now

16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch

16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch
16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch 16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch 16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch

Large Image :  16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch

Product Details:
Brand Name: Ruijie
Model Number: RG-SF2910-16GT2MG2XS-P

16-Port Gigabit Ruijie Switch With 10G Uplink VSU Stacking Managed L2 Switch

Description
Vlan Support: Yes Model: RG-S5750-H
Management Interface: Console, Telnet, Web, SNMP Security Features: Port Security, MAC Address Binding, IP Source Guard
Forwarding Rate: 104.16Mpps Port Type: 10/100/1000Base-T
Switching Capacity: 140Gbps Power Supply: AC 100-240V
Number Of Ports: 48 Power Consumption: Max. 40W
Dimensions: 440mm X 44mm X 220mm Poe Support: Yes
Highlight:

VSU Stacking Gigabit Ruijie Switch

,

10G Uplink Gigabit Ruijie Switch

,

16-Port Gigabit Ruijie Switch

16-Port Gigabit Ruijie Switch With 10G Uplink & VSU Stacking Managed L2 Switch

The Ruijie RG-SF2910-16GT2MG2XS-P is a high-performance Layer 2 managed switch designed for SMBs, enterprise branches, and campus networks. Featuring 16x Gigabit Ethernet ports, 2x 10G SFP+ uplinks, and VSU (Virtual Switching Unit) stacking support, this switch delivers scalable, high-speed connectivity with advanced management and security features.

Key Features & Benefits

16x Gigabit Copper Ports + 2x 10G SFP+ Uplinks – Ensures high-bandwidth access for workstations, IP cameras, and servers, while 10G uplinks prevent bottlenecks in aggregation.
VSU Stacking Technology – Allows multiple switches to operate as a single logical device, simplifying management and improving redundancy.
Advanced L2 Management – Supports VLAN, QoS, STP/RSTP, LACP, and ACLs for optimized traffic control.
Enhanced Security – Includes DHCP Snooping, IP Source Guard, Port Security, and 802.1X authentication to prevent attacks.
Silent & Energy-Efficient – Fanless design for quiet operation and IEEE 802.3az (EEE) compliance for power savings.

Technical Specifications

Category Details
Ports 16x 10/100/1000BASE-T, 2x 10G SFP+, 2x 1G SFP
Switching Capacity 56 Gbps
Forwarding Rate 41.66 Mpps
Stacking VSU (Virtual Switching Unit)
Security ACLs, Port Security, DHCP Snooping, 802.1X
Management Web GUI, CLI, SNMP, RMON, RG-SNC Cloud
Power Consumption <15W (typical)
Operating Temp. -5°C to 45°C

Ideal Use Cases

Office Networks – Reliable Gigabit-to-desktop with 10G backbone.
Surveillance (PoE Optional) – Connects IP cameras (check PoE model for power delivery).
Branch Connectivity – VSU stacking simplifies multi-site deployments.

Why Choose Ruijie?
Ruijie’s RG-SF2910-16GT2MG2XS-P combines affordability, scalability, and enterprise-grade features, making it a cost-effective solution for growing networks. Its 10G uplinks and stacking support ensure future-ready performance, while advanced security protects against threats.
