Ruijie Switch RG-S5750V2-28GT4XS-L 10G Uplink VSU Virtualization Layer 3 Routing For High-Performance Networking

Large Image : Ruijie Switch RG-S5750V2-28GT4XS-L 10G Uplink VSU Virtualization Layer 3 Routing For High-Performance Networking

Product Details:

Brand Name:	Ruijie
Model Number:	RG-S5750V2-28GT4XS-L

Contact Now

Ruijie Switch RG-S5750V2-28GT4XS-L 10G Uplink VSU Virtualization Layer 3 Routing For High-Performance Networking

Description

Dimensions:	440mm X 220mm X 44mm	Vlan Support:	Yes
Forwarding Rate:	41.7Mpps	Port Type:	Gigabit Ethernet
Redundancy Support:	STP, RSTP, MSTP	Port Number:	24
Product Type:	Switch	Management Interface:	Web, CLI, SNMP
Security Features:	Port Security, Access Control List (ACL)	Qos Support:	Yes
Switching Capacity:	56Gbps	Power Consumption:	Max. 20W
Product Model:	RG-S2910G-E	Power Supply:	Internal Power Supply
Highlight:	10G Uplink Switch , RG-S5750V2-28GT4XS-L Switch

Ruijie Switch RG-S5750V2-28GT4XS-L 10G Uplink VSU Virtualization & Layer 3 Routing For High-Performance Networking

The Ruijie RG-S5750V2-28GT4XS-L is a high-performance Layer 3 Gigabit Ethernet switch designed for enterprise core and aggregation networks. It features 28x Gigabit Ethernet ports, 4x 10G SFP+ uplinks, and advanced VSU (Virtual Switching Unit) technology, making it ideal for scalable and resilient network deployments.

Key Features & Benefits

High-Speed Connectivity - 28x 10/100/1000M RJ45 ports + 4x 1G/10G SFP+ ports for flexible fiber or copper uplinks
VSU Virtualization - Combine multiple switches into a single logical device for simplified management and improved redundancy
Layer 3 Routing - Supports static routing, OSPF, BGP, and IPv6, ensuring efficient traffic handling in complex networks
Advanced Security - Features IP/MAC/port binding, DAI (Dynamic ARP Inspection), and SSH encryption for secure network operations
Smart QoS & Traffic Control - 8 priority queues per port with SP/WRR/DRR scheduling, optimizing bandwidth for critical applications
Dual Power Supply (Optional) - Supports 1+1 redundancy for uninterrupted operation

Technical Specifications

Category	Details
Ports	28x 10/100/1000M RJ45, 4x 1G/10G SFP+, 4x 100/1000M SFP (shared)
Switching Capacity	672Gbps / 6.72Tbps
Forwarding Rate	228Mpps
VLAN Support	4K VLANs, Private VLAN, Voice VLAN, GVRP
Routing Protocols	Static, RIP, OSPF, BGP, IPv6
Security Features	IP/MAC binding, DAI, SSH, RADIUS/TACACS+
Management	SNMP, CLI, Web, RMON, USB backup
Power Supply	Dual modular (AC/HVDC), 45W max
Dimensions	440×280×44mm (1RU)
Warranty	1-3 years (varies by supplier)

Ideal Use Cases

Enterprise Core/Aggregation - High-speed backbone with 10G uplinks
Campus Networks - Scalable and secure with VSU & Layer 3 routing
Data Centers - Redundant power and low-latency switching

This Ruijie switch delivers high availability, security, and performance, making it a top choice for modern business networks.
