CE6855-48XS8CQ-F Huawei Network Switch 10GE/100GE Ports VXLAN Enabled

Large Image : CE6855-48XS8CQ-F Huawei Network Switch 10GE/100GE Ports VXLAN Enabled

Product Details:

Place of Origin:	China
Brand Name:	Huawei
Model Number:	CE6855-48XS8CQ-F

Payment & Shipping Terms:

Price:	¥500-130000
Packaging Details:	According to customer needs
Delivery Time:	7-15 work days
Payment Terms:	L/C,D/A,D/P,T/T,Western Union,MoneyGram

Contact Now

CE6855-48XS8CQ-F Huawei Network Switch 10GE/100GE Ports VXLAN Enabled

Description

Power Supply:	AC 110/220V	Switching Capacity:	128 Gbps
Weight:	3.2 Kg	Forwarding Rate:	88 Mpps
Memory:	1 GB	Operating Humidity:	5% To 95%
Management Interface:	Console Port, Ethernet Port, USB Port	Flash Memory:	512 MB
Highlight:	ce6855-48xs8cq-f huawei network switch , huawei network switch 10ge , ce6855-48xs8cq-f huawei 48 port switch

High - Density 10GE/100GE Ports , M - LAG For Reliability , VXLAN - Enabled : Huawei Switch CE6855 - 48XS8CQ - F

The Huawei Switch CE6855 - 48XS8CQ - F is a high - performance networking solution designed for data centers and large - scale enterprise networks.

One of its key features is the high - density port configuration. It comes with 48 10GE SFP+ ports, allowing for the connection of numerous servers or network devices. The 8 100GE QSFP28 ports, which can also be used as 40GE QSFP+ interfaces or split into 25GE SFP28 or 10GE SFP+ interfaces, provide ultra - fast uplink connections, enabling seamless integration with other core network devices.

Reliability is a top priority for this switch. With Multi - chassis Link Aggregation Group (M - LAG) support, it ensures link reliability is elevated from the single - board level to the device level, offering multi - active system traffic load sharing and backup protection. The redundant power supply and hot - swappable fan modules further enhance its reliability, ensuring continuous operation even in the event of component failures.

In terms of data center functionality, the switch excels with VXLAN support. It can serve as a high - performance hardware gateway for Overlay virtualization networks, supporting up to 16M multi - tenants. The integration with BGP - EVPN simplifies VXLAN configuration, and the OpenAPI allows for seamless integration with cloud platforms.

Parameter Table:

Parameter	Details
Model	CE6855 - 48XS8CQ - F
10GE SFP+ Ports	48
100GE QSFP28 Ports	8 (Can be used as 40GE QSFP+ or split)
Link Aggregation	Supports M - LAG
Power Supply	Dual power modules, 1+1 backup
Fan Modules	Hot - swappable, support hot backup
VXLAN Feature	Supports up to 16M multi - tenants, BGP - EVPN as control plane

The Huawei Switch CE6855 - 48XS8CQ - F thus combines high - density connectivity, robust reliability, and advanced data center features, making it an ideal choice for modern network infrastructure.
