Forwarding Rate: | Up To 357.14 Mpps | Port: | 48 |
---|---|---|---|
Color: | Black | Redundancy Features: | Hot Standby Router Protocol (HSRP), Virtual Router Redundancy Protocol (VRRP) |
Multicast Support: | IGMP, PIM, MSDP | Model: | Catalyst 9300 Series |
Transmission Rate: | 10/100/1000Mbps | Downlinks: | 24 Ports Full PoE+ |
Uplink: | 4 X 1G SFP Ports | Dimensions: | 17.5 X 1.75 X 17.5 Inches |
Poe Support: | Yes | Speed: | 10/100/1000/10000/40000/100000 Mbps |
Number Of Ports: | 24/48/96/144 | Products Status: | Stock |
Cisco Switch Catalyst 9132T : 8-Port Multi-Gig PoE++ for Wi-Fi 6 & IoT StackWise-80 & DNA Ready
The Cisco Catalyst 9132T-8PM-ISK9 is a compact, high-performance access switch designed for modern Wi-Fi 6 (802.11ax) and IoT deployments. With 8x Multi-Gigabit Ethernet ports supporting PoE++ (60W per port), it powers bandwidth-intensive devices like wireless access points, IP cameras, and digital signage while delivering future-proof scalability.
✔ High-Density PoE++: 8x 1/2.5/5/10Gbps ports with IEEE 802.3bt (PoE++) support for high-power devices.
✔ Multi-Gig Speeds: 2.5Gbps uplinks ensure seamless Wi-Fi 6/6E backhaul and 4K video streaming.
✔ StackWise-80 Technology: Stack up to 8 units with 80Gbps bandwidth for simplified management.
✔ Cisco DNA Ready: Automated provisioning, AI-driven analytics, and zero-touch deployment via Cisco DNA Center.
✔ Enterprise Security: MACsec encryption, Secure Boot, and Cisco TrustSec for role-based access control.
✔ IoT Optimized: USB 3.0 port and Flexible NetFlow support for IoT device connectivity and monitoring.
Parameter | Details |
---|---|
Ports | 8x 10/100/1000/2500/5000/10000BASE-T (PoE++), 2x SFP+ uplinks |
PoE Budget | 240W total (60W per port, IEEE 802.3bt) |
Stacking | StackWise-80 (80Gbps backplane, up to 8 units) |
Security | MACsec-256, Secure Boot, TrustSec, ACLs |
Management | Cisco DNA Center, CLI, Web UI, SNMP |
Dimensions | 1.72 x 8.5 x 7.9 in (desktop/rack-mountable) |
Power Options | External AC power supply (redundant optional) |
Ideal for high-density wireless networks, smart buildings, and hybrid workplaces, the Catalyst 9132T-8PM-ISK9 combines Multi-Gig speeds, advanced PoE, and AI-driven automation in a compact form factor. Its integration with Cisco DNA Center enables intent-based networking, reducing operational overhead while ensuring scalability.
